| Active or Passive |
Passive |
| System Type |
Array Element |
| Configuration |
2-way |
| System Continuous Power |
Passive: 400 W / Bi-amp LF: 400 W / Bi-amp HF: 90 W |
| System Programme Power |
Passive: 800 W / Bi-amp LF: 800 W / Bi-amp HF: 180 W |
| System Peak Power |
Passive: 1600 W / Bi-amp LF: 1600 W / Bi-amp HF: 360 W |
| Max SPL @ 1m |
132 dB |
| Freq Response (+/-3 dB) |
70 Hz – 20 KHz |
| Freq Range (-10 dB) |
65 Hz – 20 KHz |
| Bi-amp Mode Switch |
Yes |
| Bluetooth |
No |
| IP Certification |
None |
| Driver Brand |
Wharfedale Pro |
| LF Driver Size |
2 x 8" |
| LF Magnet Material |
Ferrite |
| LF Frame Material |
Aluminium |
| LF Voice Coil Size |
2″ |
| LF Rated Impedance |
8 Ω |
| LF Power (RE:AES2-2012) |
2 x 200 W |
| HF Driver Type |
Compression Driver |
| HF Voice Coil Size |
3.2" |
| HF Diaphragm Material |
Titanium |
| HF Exit Size |
1.4″ |
| HF Power (RE:AES2-2012) |
80 W |
| HF Rated Impedance |
8 Ω |
| Preset Library |
Yes |
| Input Connector |
2 x 4 Pole speaker connector |
| Waveguide Type |
Coherent Array Shaping Technology (CAST) |
| Enclosure Material |
Birch Plywood |
| Grille Material and Finish |
Steel Black |
| Finish |
Black Tough-Tone |
| Handles |
2 |
| Deployment |
Ground, Flying |
| Pole Mount |
None |
| Rigging |
Yes |
| Integral Rigging |
3 Points |
| Nominal Coverage (H x V) |
100° x System dependant |
| Sensitivity 2.83 V / 1 M |
100 dB |
| System Rated Impedance |
Passive: 16 Ω / Bi-amp LF: 16 Ω / Bi-amp HF: 16 Ω |
| Crossover Frequency |
1.8 KHz |
| Recommended HPF = BW 18 dB/OCT. |
65 Hz |
| Included Accessory |
User Manual |
| Unpacked - Front Height (mm) |
250 |
| Unpacked - Rear Height (mm) |
188 |
| Unpacked - Width Front (mm) |
760 |
| Unpacked - Width Rear (mm) |
760 |
| Unpacked - Depth (mm) |
424 |
| Packed - Height (mm) |
375 |
| Packed - Width Front (mm) |
545 |
| Packed - Width Rear (mm) |
545 |
| Packed - Depth (mm) |
855 |
| Weight - Nett (kg) |
27 |
| Weight - Gross (kg) |
33 |
