| Active or Passive |
Active |
| System Type |
Full-Range |
| Configuration |
2-way |
| System Continuous Power |
720 W |
| System Peak Power |
1440 W |
| Max SPL @ 1m |
127 dB |
| Freq Range (-10 dB) |
60 Hz - 20 kHz |
| Freq Response (+/-3 dB) |
65 Hz - 20 kHz |
| Bluetooth |
Yes |
| IP Certification |
IP54 |
| Driver Brand |
Wharfedale Pro |
| LF Driver Size |
8" |
| LF Voice Coil Size |
2.5" |
| LF Rated Impedance |
4 Ω |
| LF Power (RE:AES2-2012) |
200 W |
| HF Driver Type |
Compression Driver |
| HF Voice Coil Size |
1.75" |
| HF Diaphragm Material |
Titanium |
| HF Exit Size |
1" |
| HF Power (RE:AES2-2012) |
40 W |
| HF Rated Impedance |
8 Ω |
| HF Nominal Coverage (H x V) |
100° x 80° |
| Input Connector |
2 x 1/4” Jack / XLR Combo, 2 x RCA, BT |
| Waveguide Type |
Hybrid Symmetry Horn |
| Enclosure Material |
Polypropylene |
| Grille Material and Finish |
Steel Black |
| Finish |
Black Polypropylene |
| Handles |
4 |
| Deployment |
Flying, Pole, Wall Mount, Ground |
| Pole Mount |
35 mm With Lock Screw |
| Rigging |
Yes |
| M8 |
9 |
| Sensitivity 2.83v / 1m |
96 dB |
| System Rated Impedance |
n/a |
| Crossover Frequency |
2.3 kHz |
| Recommended HPF = BW 18 dB/OCT. |
60 Hz |
| Amplifier design |
Class D |
| Preset list |
Flat / Monitor / Bass / Punch (with FIR) |
| Active loudspeaker Input Impedance |
20 KΩ |
| Link Connector |
pin XLR |
| Input sensitivity |
775 mV (0 dBu) |
| Max input level |
4 V |
| Line output |
Pin XLR |
| DSP Controls |
Flat / Monitor / Bass / Punch (with FIR) |
| Main Power |
100-120 V~/200-240 V~,50/60 Hz |
| Power Supply |
SMPS |
| Unpacked - Height (mm) |
434 |
| Unpacked - Width Front (mm) |
256 |
| Unpacked - Width Rear (mm) |
100 |
| Unpacked - Depth (mm) |
240 |
| Packed - Height (mm) |
509 |
| Packed - Width Front (mm) |
326 |
| Packed - Width Rear (mm) |
326 |
| Packed - Depth (mm) |
310 |
| Weight - Nett (Kg) |
10.7 |
| Weight - Gross (Kg) |
12.7 |
