FEATURES
- Supports
- 3D HDMI
- YUV 4:4:4
- HDR
- HDMI2.0 and HDCP2.2 Compliant
- Allows simultanious mixed 4K and 1080p display outputs
SPECIFICATIONS:
Transmission rate :18Gbps
Input : 1× HDMI (Type-A, 19-Pin, Female)
Output : 2× HDMI (Type-A, 19-Pin, Female)
Input cable length : ≤5m (AWG26 HDMI2.0 cable support)
Output cable length : ≤5m (AWG26 HDMI2.0 cable support)
Video support : 480i @60Hz, 480p @60Hz, 576i @50Hz, 576p @50Hz, 720p @50/60Hz, 1080i @50/60Hz, 1080p @50/60Hz, 4K @24/25/30/60Hz
Audio format : Supports standard audio and DSD (Direct Stream Digital) and HD (HBR) audio
ESD protection : ±8kV (air-gap discharge), ±4kV (contact discharge)
TMDS signal : 0.7 ~ 1.5Vp-p (TMDS)
DDC signal : 5Vp-p (TTL)
HDR : Yes
HDCP : HDCP2.2
Housing : Metal enclosure
Dimensions : (L × W × H) 96 × 59 × 16.8mm
Net weight : 100g
Power supply : DC5V 1A
Power consumption : <2.5W
Operation temperature : 0~60°C
Storage temperature : -20~70°C
Relative humidity : 20-90% (no condensation)
